VLX 100 Pivot Door

VLX 100 Pivot Door in Dallas, TX | Meridian Windows and Doors Dallas

The VLX 100 Pivot Door is a heavy-duty aluminum entry door that rotates on a vertical center axis instead of swinging on side hinges, which allows for dramatically oversized glass panels and a clean architectural profile. It’s the kind of statement piece buyers choose for modern builds in Preston Hollow, contemporary remodels in East Dallas, and lakefront properties around White Rock Lake. As an authorized ViewLux installation partner, Meridian Windows and Doors Dallas supplies, installs, and services this exact door system across the Dallas-Fort Worth metro. We handle everything from first measurement to final seal and cleanup. Call (325) 309-2639 to talk through your opening size, finish options, glass package, and a realistic timeline for installation in Dallas.

Call (325) 309-2639

Product Overview – VLX 100 Pivot Door

The VLX 100 Pivot Door is built around a straightforward design idea: eliminate the visual weight of a traditional hinged frame and let the glass do the work. Instead of hinges mounted to one side jamb, the door rotates on pivot hardware set into the floor and header, which spreads the load across the full panel height. That’s what lets a door this size function reliably in a Dallas home where temperature swings and foundation movement are realities.

Aluminum is the structural backbone here, and it’s chosen for good reason. A wood door of this scale would sag within a few Texas summers. Aluminum holds its shape. The frame profile runs 2.56 inches deep, which is substantial enough to carry an oversized panel without visible flexing when the wind presses against it. Wall thickness on the frame members measures 0.098 inches, in the range you’d expect from a commercial-grade aluminum system rather than a lightweight residential screen door.

We see this product specified most often on entryways that face the street but still want light, on courtyard entries where privacy is handled by the glass selection, and on the back elevation of homes in neighborhoods like Lakewood or Kessler Park where the pivot door opens onto a patio or pool. It is an architectural object as much as a door. Buyers who choose it are usually working with a designer, an architect, or have a clear idea of the modern look they want. Meridian Windows and Doors Dallas is one of the few local Dallas teams actually authorized to install ViewLux products, which matters when warranty support and long-term service come into play.

Technical Specifications

Here are the numbers that define the VLX 100 Pivot Door system, in plain terms:

• Frame profile width: 2.56 inches, the visible face depth of the aluminum frame when looking at the opening from inside or out.
• Wall thickness: 0.098 inches, a heavier-gauge aluminum extrusion that resists twisting and keeps the pivot hardware true over time.
• Maximum panel size: up to 60 inches wide by 120 inches tall, which covers most oversized entry openings in Dallas homes from the 1980s onward and works for many new-construction great-room entries.
• Glass options: Clear, Frosted, Obscure, Low-E, Tempered, and Laminated, each available in single or dual-pane configurations depending on the performance spec.
• Finish options: Premium Black, Pure White, Anodized Silver, Bronze, Champagne, and Teak Wood, all applied as a coating system designed for UV exposure.
• Hardware configuration: Floor-to-header pivot system with top and bottom pivot points, sized to the panel weight at your exact dimensions.

Every VLX 100 door we order for a Dallas customer is sized to the rough opening and specified with local wind-load requirements in mind. There is no “stock size” approach. What gets delivered is built for your specific entry, not trimmed out of a warehouse pallet.

Performance Features

Thermal Efficiency – The VLX 100 uses a thermally broken aluminum frame, which means there is a non-conductive material separating the interior and exterior aluminum faces. That break prevents heat from conducting through the metal. In Dallas, where July afternoons routinely hit 100°F and the sun pounds west-facing entries, this is the difference between a door that feels warm to the touch and one that radiates heat into the hallway. NFRC-rated performance data applies to the glazing package as a whole.

Acoustic Performance – A laminated glass package in the pivot panel cuts exterior noise noticeably, which matters along Mockingbird Lane, Highway 75 corridors, or any street with consistent traffic. The mass of the aluminum panel combined with laminated glass reduces the mid- and high-frequency sound that travels through standard double-pane residential doors.

Airtightness & Weather Seal – All perimeter joints around the VLX 100 frame receive AAMA 812 low-expansion foam sealant, which prevents air from moving between the rough opening and the frame. This is a specific installation standard, and it matters: a door this large can lose meaningful conditioned air through even small perimeter gaps if the install is sloppy.

Waterproofing – The sill and threshold design on the pivot door channels water away from the interior when installed correctly. Our Dallas install crew follows AAMA 2400/2410 installation standards on every pivot door, and our water testing after install confirms the seal holds before we walk away from the job.

Wind Resistance – Dallas sits in a wind zone that requires exterior openings to withstand meaningful lateral pressure, especially on elevated or exposed elevations. The VLX 100 is wind-load rated for the local climate requirements we file with the permit package, and oversized panels get engineered hardware to match. This is not a door we “eyeball” on wind load.

Security & Hardware – The pivot hardware on the VLX 100 is engineered to the panel weight at your exact size, which means the top and bottom pivot points are not an afterthought. Laminated glass resists forced entry much better than standard annealed glass, and the locking mechanism on an oversized pivot door engages differently than a standard deadbolt setup, which is worth discussing during your consultation in Dallas.

Color & Glass Options

The VLX 100 comes in six finish options, and the right choice depends on the architectural language of your Dallas home. Premium Black is the most requested finish right now, especially on white brick modern exteriors and against light stucco. Pure White works on traditional facades where the door should read as part of the wall plane rather than an accent. Anodized Silver has a raw aluminum feel that reads commercial and works well on mid-century homes in the M Streets and Casa Linda. Bronze and Champagne bridge the gap between modern and transitional, with bronze pairing especially well with dark stone and wood siding. Teak Wood is a woodgrain finish that gives the aluminum frame a warm, natural look without the maintenance issues of an actual wood door in Dallas humidity and heat.

On the glass side: Clear is for maximum light and unobstructed views. Frosted diffuses light but blocks sight lines, which is common for front entries where you want daylight but not visibility into the foyer. Obscure is a more aggressive privacy option. Low-E is the coating that reflects solar heat, and we specify it on almost every sun-facing entry in Dallas. Tempered is a safety-glass requirement for doors under Texas code. Laminated glass is the impact-resistant option, made with an interlayer that holds the pane together if struck, and it also delivers the best acoustic performance.

Installation by Meridian Windows and Doors Dallas in Dallas

A pivot door of this size does not forgive a rough install. There’s no way to adjust a poorly set pivot and call it good. That’s why we run a structured process on every VLX 100 installation in Dallas, from initial site visit to final inspection.

It starts with a pre-install inspection of the rough opening. We measure in three places on every side, check the substrate for flatness, and verify that the floor and header can carry the point load of a pivot system. If the slab has a low spot or the header has settled, that gets addressed before the door ever arrives. In Dallas specifically, we see slab movement on older homes in neighborhoods like Lake Highlands and Casa View, and a pivot door magnifies any floor unevenness because the rotating panel sweeps across the floor plane. Every trim nail and shim has to be accounted for.

On install day, the frame goes in level, plumb, and square. That phrase matters more on a pivot door than on almost any other door style, because the pivot hardware depends on both the floor pivot and header pivot being aligned within a tight tolerance. We use laser levels, not bubble levels, on every one of these installs. The perimeter gets AAMA 812 low-expansion foam sealant on all joints, which seals air, prevents water intrusion, and allows for the thermal expansion and contraction Dallas temperatures put the aluminum through. The installation follows AAMA 2400/2410 standards, which covers preparation, flashing, and sealing. After the panel is hung and the hardware is dialed in, we run a water test on the threshold and perimeter, adjust the sweep, and clean the site before doing a walkthrough with the homeowner.

One thing we state plainly to every Dallas customer: an improperly installed pivot door voids the manufacturer warranty. ViewLux warrants the product, but the warranty assumes competent, certified installation. Meridian Windows and Doors Dallas is an authorized ViewLux partner for exactly this reason. We install it the way the manufacturer intended, so the warranty stands, the door operates correctly on day one, and it keeps operating correctly ten years later.

Frequently Asked Questions – VLX 100 Pivot Door

Get a Quote – VLX 100 Pivot Door in Dallas

If you’re building or remodeling in Dallas and want the VLX 100 Pivot Door specified, priced, and installed correctly, let’s talk. We’ll schedule a free on-site measurement, review glass and finish options against your home’s orientation and style, and give you a written line-item quote with no surprises later. Call (325) 309-2639 to start your project.

Written by the team at Meridian Windows and Doors Dallas, authorized ViewLux installation partner serving Dallas, TX.
